REPAIR SERIES - Remote/Shade Programming - SOMFY RTS

Writer's picture: Pulse Blind WorxPulse Blind Worx

How to Program a Somfy Remote: A Step-by-Step Guide


Somfy remote controls are designed to operate motorized window coverings like roller blinds, shades, and shutters. Programming a Somfy remote involves pairing it with the motor, setting the limits (top and bottom positions), and adjusting other settings. Here’s how to do it.


What You’ll Need:

  • Somfy motorized blinds or shutters

  • Somfy remote control

  • A powered Somfy motor (already installed)

  • A Paperclip

  • A flathead screwdriver (optional)

  • Access to the user manual (optional but helpful)


Step 1: Ensure the Motor is Powered On

Before programming your Somfy remote, ensure that your motorized blinds, shutters, or shades are properly powered. If you’re using a battery-powered motor, check that the batteries are fully charged. For mains-powered motors, confirm that the system is plugged in.


Step 2: Put the Motor into Programming Mode

To pair your Somfy remote with the motor, you need to put the motor into programming mode. Here’s how:


  1. Locate the programming button on the motor. This button is typically found near the motor head or on the side of the motor housing. Some Somfy motors might require a small tool (such as a screwdriver or key) to press the button.

  2. Press and hold the programming button for about 5-10 seconds. You’ll know the motor is in programming mode when it begins to flash or beep, signaling it is ready to be paired.


Step 3: Pair the Remote with the Motor

Now that the motor is in programming mode, it's time to pair the remote. Here’s how to do that:


  1. Prepare the remote: On your Somfy remote, locate the “Program” or “MY” button, usually located at the top or bottom of the remote.

  2. Activate pairing mode on the remote: Press and hold the “Program” button on the remote until the LED light on the remote flashes. This typically takes around 3-5 seconds.

  3. Pair the remote with the motor:

    • Once the remote LED starts flashing, press and hold the “Up” or “Down” button on the remote to signal the motor to pair. The motor should respond by either moving slightly or flashing again to indicate successful pairing.

    • If the pairing is successful, the remote’s LED will stop flashing.


Step 4: Set the Limits (Top and Bottom Positions)

To ensure your blinds or shades stop at the right places when you press the "Up" or "Down" buttons, you need to set the top (open) and bottom (closed) limits.


  1. Set the top limit (open position):

    • Press and hold the “Up” button on the remote until the blind moves to the fully open position.

    • Release the button when the blind reaches the desired top position. The motor will remember this as the "Up" or open limit.


  2. Set the bottom limit (closed position):

    • Press and hold the “Down” button on the remote until the blind moves to the fully closed position.

    • Release the button once it reaches the desired bottom position. The motor will store this as the "Down" or closed limit.


  3. Save the limits:

    • After setting both the top and bottom limits, press the “Program” or “MY” button on the remote again to save the limits. The motor should respond with a slight movement or flashing to indicate the limits have been saved.


Step 5: Test the Remote and Limits

Now that you’ve set the limits, it’s time to test everything:

  1. Press the “Up” button on the remote to see if the blinds raise to the top position.

  2. Press the “Down” button on the remote to make sure the blinds close completely.

  3. Test the movement and confirm that the blinds stop at the right places. If needed, you can adjust the limits by repeating the limit setting process.


Step 6: Additional Features (Optional)

Depending on your Somfy remote and motor model, you may have additional features to program, such as tilt control, group control, or timer settings.


  1. Tilt control: If your Somfy system supports tilting (for venetian blinds or shutters), you may be able to adjust the slats’ angle. Refer to your remote's manual for specific tilt instructions.

  2. Group control: If you have multiple blinds or shades and want to control them simultaneously, you can group them together on a single remote. To do this, program each motor to the same button or group.

  3. Timer settings: Some Somfy remotes allow you to set specific times for your blinds to open or close automatically. This feature can be useful for enhancing home automation.


Step 7: Resetting the Remote or Motor (If Necessary)

If you ever need to reset the remote or motor to clear the settings and start over, follow these steps:


  1. Reset the remote: Hold the “Program” button on the remote for 10 seconds until the LED light flashes rapidly. This will erase all saved settings on the remote.

  2. Reset the motor: To reset the motor, press and hold the motor’s programming button for 20-30 seconds. This will erase all previously saved settings. Once reset, you’ll need to redo the pairing and limit setting process.


Troubleshooting Tips

  • Remote doesn’t pair with the motor: If your remote isn't pairing, double-check that the motor is in programming mode. Make sure the remote is in pairing mode and that the batteries are fresh.

  • Limits not saving: If the limits aren’t saving, make sure you're holding the buttons long enough when setting the positions. The motor must be in programming mode for the limits to register.

  • Motor doesn’t respond: Ensure the motor is powered on, and try re-pairing the remote. If the issue persists, the motor or remote might need further troubleshooting or professional assistance.


Conclusion

Programming your Somfy remote involves pairing the remote with the motor, setting the open/close limits, and ensuring smooth operation. While the process may seem complex, it is fairly straightforward when you follow these steps. Once programmed, your remote will allow you to effortlessly control your motorized blinds or shades.

If you encounter any difficulties, always refer to your user manual for your specific Somfy model. Alternatively, you can reach out to Somfy’s customer support for additional assistance.

For visual aids or further details, I recommend checking the Somfy website or referring to the user manual that came with your motorized window covering system. You can also search for video tutorials on platforms like YouTube, where you may find a detailed video of the exact steps for your Somfy model.



If you need help, you can book an appointment here: https://www.pulseblindworx.com/book
